30 cbm agricultural transfer trailer
EGRITECH BNP-30
Description:
Agricultural transfer trailer, with 2 axles, which can be used in the harvesting and transfer activities to the seeders.
Chassis:
Made entirely of steel profiles, closed tube type.
2 running axles, with mechanical suspension (leaf springs), pneumatic or hydraulic braking system, with parking brake.
Rear bumper, foldable.
Fixed drawbar, towing coupling with D50 eye, parking support leg (hydraulic actuated).
4 wheels with steel rims and 600/55 R26.5 or 650/55 R26.5 tires.
12V electrical system, with lighting installation according to road traffic.
PVC tool box mounted on the chassis.
Wheel protection mudguards.
Body:
Monocoque body, made of steel sheet, specially profiled for increased resistance.
Bondioli & Pavesi gearbox model S2100 and transmission shaft.
Technofer (Italy) hydraulically operated horizontal auger with viewing windows for cleaning operations.
Technofer vertical transfer auger, with adjustable unloading height, hydraulically operated, folding.
Side rolling tarpaulin, with operating bar at ground level.
Bunker access ladder mounted on the side.
Work lamp mounted on auger.
Bunker lighting lamp.
Special bunker paint for increased protection.
TECHNICAL DATA:
| EGRITECH BNP-30 | |
| Gross weight (kg) | 31.300 |
| Own weight (kg) | 8.800 |
| Technical payload (kg) | 22.500 |
| Drawbar permitted weight (kg) | 3.000 |
Total dimensions: Length (mm) Width (mm) Height (mm) |
8.450 3.150 4.150 |
| Bunker volume (cbm) | 30 |
| Side walls thickness (mm) | 3 / 4 |
| Floor thickness (mm) | 5 |
| Wheel track (mm) | 2.300 |
| Axles distance (mm) | 1.525 |
| Number of axles | 2 |
| Maximum hydraulic pressure (bar) | 220 |
| Minimum pilling tractor recommended power (HP) | 220 |
| Maximum speed (km/h) | 30 |
| Transfer (unloading) speed (to/h) | 360 |
| Auger diameter (mm) | 500 |
| Auger unloading height (mm) | 3.600 ~ 4.300 |
